SMT fuse protects tip and ring circuits
May 2006
Fieldbus & Industrial Networking
Schurter is offering its TF 600 non-resettable fuse designed to assist manufacturers of telecommunications equipment in meeting power cross and lightning surge requirements outlined in North American standards Telcordia GR-1089, TIA-968-A (formerly FCC Part 68), and UL 60950, as well as the international standards ITU-T K.20 and IEC 60950. The fuse has a rated breaking capacity of 60 A at 600 V a.c. over a current range of 0,5 to 2 A.
The TF 600 is RoHS compliant according to Directive 2002/95/EC. Its low profile and small footprint conform to industry norms for size, placement and process compatibility. Its time-lag tripping characteristic provides reliable secondary protection of secondary circuits in a variety of telecom systems and networking equipment designated for use around the world. Typical applications are customer premises equipment (CPE) like telephones and modems, high-speed transmission equipment like ADSL modems and splitters and analog line cards (SLICs).
The TF 600 is built to UL 248-14 and carries UL/CSA recognition. It also holds a 'Free of CCC' confirmation for China. It is supplied either on tape (2000 pieces) or loose in a bag (100 pieces).
