CNC cycle package for triple-axis milling and drilling

November 2023 Fieldbus & Industrial Networking

Image copyright: Beckhoff Automation.

Beckhoff provides a comprehensive package of different cycles for triple-axis milling and drilling machines with the TwinCAT 3 CNC milling base. It facilitates programming for these machines by encapsulating the required processes in parameterisable and reusable modules.

The new TwinCAT CNC cycle package supports a variety of different drilling strategies, ranging from simple centring and deep hole drilling to helical milling, tapping and thread milling. These can also be combined with the included cycles for drilling patterns to facilitate efficient programming for multiple drilling in various arrangements. The milling cycles also optimally support the production of slotted holes, grooves and differently shaped pockets and tenons. This includes an option for producing customer-specific pockets or tenons based on contour descriptions stored in the CNC program, removing remaining residual material using a separate tool, and deburring the resulting milled edges. All cycles offer extensive parameterisation options for adaptation to different technological requirements. Their many features include support for different machining modes (roughing and finishing) and feed directions (conventional or climb milling). These can be used in all principal planes (G17, G18 and G19).
